10"
CL 10'' Series
1 SELECT FRAME
10008H
CL-10, 10”,Commercial
New Construction
10008
CL-10, 10”,Architectural
New Construction Frame
10008R
CL-10, 10”,Architectural
Remodel Frame
2 SELECT POWER MODULE WATTAGE AND CCT
Non-IC and
Remodel Module
Non-IC and
Remodel Dim to Warm power Module
|
Watts |
CCT |
CRI |
Lumens |
Voltage |
Dimming |
| 16W | 2700K | 90 | 1200-1300 | 120-277V | Tri-D |
| 16W | 3000K | 90 | 1200-1300 | 120-277V | Tri-D |
| 16W | 3500K | 90 | 1200-1300 | 120-277V | Tri-D |
| 16W | 4000K | 80 | 1200-1300 | 120-277V | Tri-D |
| 25W | 2700K | 90 | 1950-2050 | 120-277V | Tri-D |
| 25W | 3000K | 90 | 1950-2050 | 120-277V | Tri-D |
| 25W | 3500K | 90 | 1950-2050 | 120-277V | Tri-D |
| 25W | 4000K | 80 | 1950-2050 | 120-277V | Tri-D |
| 38W | 2700K | 90 | 2900-3000 | 120-277V | Tri-D |
| 38W | 3000K | 90 | 2900-3000 | 120-277V | Tri-D |
| 38W | 3500K | 90 | 2900-3000 | 120-277V | Tri-D |
| 38W | 3500K | 80 | 2900-3000 | 120-277V | Tri-D |
| 38W | 4000K | 80 | 2900-3000 | 120-277V | Tri-D |
| 50W | 3000K | 90 | 3900-4000 | 120-277V | Tri-D |
| 50W | 3500K | 90 | 3900-4000 | 120-277V | Tri-D |
| 50W | 3500K | 80 | 3900-4000 | 120-277V | Tri-D |
| 50W | 4000K | 80 | 3900-4000 | 120-277V | Tri-D |
| 70W | 3000K | 90 | 5900-6000 | 120-277V | Tri-D |
| 70W | 3500K | 80 | 5900-6000 | 120-277V | Tri-D |
| 70W | 4000K | 80 | 5900-6000 | 120-277V | Tri-D |
| 100W | 3500K | 80 | 6900-7000 | 120-277V | Tri-D |
| 100W | 4000K | 80 | 6900-7000 | 120-277V | Tri-D |
INDICATE OPTIC BY ADDING TRIM TYPE INDICATOR TO THE ITEM NUMBER WHERE INDICATED BY AN "X"
3 SELECT REFLECTOR AND OPTIC COMBINATION
Matte White
Clear Specular
Haze[
INDICATE OPTIC BY ADDING TRIM INDICATOR
TO THE END OF THE PRODUCT NUMBER.
|
Color |
Style |
| Matte White | Self Flanged |
| Clear Specular | Self Flanged |
| Haze Diffuse | Self Flanged |
|
Trim Type |
Indicator |
| Narrow Beam | N |
| Medium Beam | M |
| Wide Beam | W |
High output reflectors use with 70W and 100W
|
Color |
Style |
| Matte White | Self Flanged，Medium Beam |
| Matte White | Self Flanged，Wide Beam |
| Clear Specular | Self Flanged，Medium Beam |
| Clear Specular | Self Flanged，Wide Beam |
| Haze Diffuse | Self Flanged，Medium Beam |
| Haze Diffuse | Self Flanged，Wide Beam |
SELECT OPTIONAL ACCESSORIES
Narrow Optics
Medium Optics
Wide Optics
Wall Grazer
|
Accessories Optic |
| Optic, Narrow |
| Optic, Medium |
| Optic, Wide |
| Optic, HO, Medium |
| Optic, HO, Wide |
| Optic, Wall Grazer |
Matte White
Clear Specular
Haze
|
Wet Location Trim Accessories- Snap into Standard Reflectors |
| Reflector, 10'', Matte White, Wet LOC, Frosted Lens, Self Flanged |
| Reflector, 10'', Clear Specular, Wet LOC, Frosted Lens, Self Flanged |
| Reflector, 10'', Haze, Wet LOC, Frosted Lens, Self Flanged |
